GDS® Type-C and Type A 2-Port Cigarette Charger - RAM-GDS-CHARGE-PPS-CIGC

This two-port GDS^® USB Type-C and USB Type-A cigarette charger (RAM-GDS-CHARGE-PPS-CIGC) allows for charging two devices simultaneously. The USB Type-A port takes advantage of Qualcomm^® Quick Charge^™ 3.0 for compatible devices. With the USB Type-C port, utilize full 30W power delivery. To prevent overcharging and overheating, multiple built-in safeguards protect against over-current. The updated low-profile design now fits more flush in the vehicle’s charging socket, along with support of PPS and PD3.0 for better support for iPads and dynamic PD support.

FEATURES

• Two-port GDS^® USB Type-C and USB Type-A cigarette charger; total output of 48W max

• USB Type-C port utilizes full 30W power delivery; built-in safeguards protect against over-current

• Supports PPS and PD3.0

• Backed by a 3-year warranty

INPUT VOLTAGE
12-24VDC

POWER OUTPUT
48W Total (30W for Type-C & 18W for Type-A)

OUTPUT CURRENT
3A max

OPERATING TEMPERATURE
-10°C to +50°C

STORAGE TEMPERATURE
-20°C to +70°C

PORTS
(1) Type-C Female (PD)
(1) Type-A Female (QC 3.0)

COMPLIANCE
Short Circuit Protection, Over Voltage Protection, Over
Current Protection & Over Temperature Protection

CERTIFICATIONS
FCC, Industry Canada, CE, RoHS, WEEE

WARRANTY
3 year warranty

WEIGHT
0.12 lb
