RAM® EZ-Roll'r™ Drill-Down Mount for SPOT Gen4 - RAM-B-138-SPO6U

The form-fitting, high-strength composite RAM^® EZ-Roll’r^™ cradle for the SPOT Gen4^™ allows for the attachment of RAM^® components containing the universal AMPS hole pattern making it the ideal GPS mount for SPOT Gen4^™. With the device in the cradle, all buttons and the power port remain fully accessible. The RAM^® EZ-Roll’r^™ cradle for the SPOT Gen4^™ is compatible and interchangeable with a wide range of RAM^® diamond ball bases. Included is a set of two nuts and bolts. Consists of a medium length B size 1" double socket arm, one 2.5" diameter round ball base, and one diamond ball base (both bases feature the universal AMPS hole pattern). The ball and socket system provides shock and vibration damping, and allows for near-infinite adjustability to achieve an ideal viewing and operating angle of your device.

HARDWARE INCLUDED

Assembly Hardware

SOCKET-TO-SOCKET LENGTH

3"

HOLE PATTERN

4-Hole AMPS: 1.181" x 1.496"
3-Hole 120-Degree: 1.812" Diameter

PLATE SIZE

2.5" Diameter

BALL/SOCKET SIZE

B Size (1")

WEIGHT CAPACITY

Standard Use: 2 lbs
Heavy-Duty Use: 1 lb

MATERIALS

Marine-grade aluminum
High strength composite

PACKAGING TYPE

Poly Bag

WEIGHT

0.59 lbs.
