      RAM-D-247U-4-IN1

      RAM® Steel Reinforced Square Clamp Base for Posts up to 4" Wide - RAM-D-247U-4-IN1

      Out of Stock    ( Chat Live to get an ETA )

      • Clamping base ideal for square posts up to 4" in width; adjustable and easily removable
      • Included D size 2.25" reinforced RAM® rubber ball allows for connection to any D size RAM® double socket arm; ball and socket technology allows for near-infinite adjustability
      • Made of powder-coated, marine-grade aluminum for durability and reliability in the most demanding environments
      • Backed by a lifetime warranty

      OVERVIEW

      This square post mount is ideal for forklift mounting and consists of a 4" clamp base with a reinforced D size 2.25" ball for added security when mounting heavy devices. Attach any length D size socket arm, D size ball adapter and a device holder of your choosing for an ultra-rugged mounting solution for your forklift. While the base can support up to a maximum post width of 4", it can support any lesser width by rotating the base on the post, bringing the mounting bolts flush against the post.

      HARDWARE INCLUDED

       (2) 5/16"-18 x 3" Machine Screws
      (2) 5/16"-18 Nylock Nuts


      CLAMP RANGE

       4" max width


      BALL/SOCKET SIZE

       D Size (2.25")

      WEIGHT CAPACITY

       6 lbs

      MATERIALS

      Marine-grade aluminum


      PACKAGING TYPE

      Poly Bag

      WEIGHT

      1.54 lbs

      Square Post Clamp Base Assembly Guide - PDF
