      RAM-234-PAN1PB

      RAM Composite Tough-Dock Powered Cradle w/Port Rep, ROUND ADAPTER BASE for Toughbook 31 - RAM-234-PAN1PB

      Out of Stock    ( Chat Live to get an ETA )

      RAM Tough-Dock™ Powered Docking Station with Port Replication AND ROUND ADAPTER BASE for Panasonic Toughbook® CF-28, CF-29, CF-30 and CF-31 Rugged Laptops.

      Port Replication:
      (1 qty) RJ-45 LAN
      (1 qty) DC Input
      (4 qty) USB 2.0 on Replicator Board
      (1 qty) USB 2.0 on Side of Dock
      (1 qty) VGA Output
      (1 qty) DB-9 Serial Connection
      (1 qty) Speaker Out

      Standard Features:
      Single RF Pass Through
      Integrated Power Supply
      Tamper Proof Lock
      12-30 Volt DC Input
      Integrated Screen Support
      Overcurrent / Surge Protection
      Reverse Polarity Protection
      Radio Frequency Isolation
      Military Grade Construction
      External Fuse
      External Power Switch

      Regulatory Approvals:
      CE
      FCC
      TUV-CB
      e-Mark

      Warranty Information:
      3 year warranty on electrical and electronic parts
      Lifetime warranty on mechanical parts
      Lifetime warranty on all metal parts

      Material:
      High Strength Composite Enclosure & Powder Coated Marine Grade Aluminum

      Ball Size:
      1.5" Rubber Ball Size

      Weight:
      7.1 lbs.
