      RAM-B-108-STRAP40

      RAM® Large Strap Hose Clamp Base for Beechcraft and Bonanza Airplanes - RAM-B-108-STRAP40

      Out of Stock    ( Chat Live to get an ETA )

      OVERVIEW

      The RAM-B-108B-STRAP40 accommodates rails from 2" to a maximum of 3" in diameter. To mount the RAM-B-108B-STRAP40 base, place the saddle shaped plate on the rail then wrap the metal clamp strap around the rail and plate. Tighten the screw knob on the metal strap with a screw driver until the strap has a firm hold on the rail. The RAM-B-108B-STRAP40 is an alternative mounting base for aircraft such as the Bonanza or Beech with a “throw over yoke”.

      HARDWARE INCLUDED

      (1) #40 Worm Drive Strap Clamp
      (1) 6" Rubber Strip

      CLAMP RANGE

      2" - 3" diameter

      SOCKET-TO-SOCKET LENGTH

      3"

      HOLE PATTERN

      4-Hole AMPS: 1.181" x 1.496"
      3-Hole 120-Degree: 1.812" Diameter

      BALL/SOCKET SIZE

      B Size (1")

      WEIGHT CAPACITY

      Standard Use: 2 lbs
      Heavy-Duty Use: 1 lb

      MATERIALS

      Marine-grade aluminum

      PACKAGING TYPE

      Retail Bag

      WEIGHT

      0.83 lbs.
